The InfiRay TD70L V2 excels at capturing clear target details. Leverage the power of a 1980×1080 sensor with 4μm pixels for exceptional low-light sensitivity. Paired with a vibrant 1440×1080 OLED display, experience unparalleled precision and clarity in night shooting. Elevate your shooting experience with this unbeatable technology combination.
Next Level Low-Light Hunting Experience
The larger the pixel size, the more light each pixel can collect. With a pixel size of 4um, the Tube NV sensor demonstrates exceptional low-light sensitivity. Even one hour after sunset, Tube NV devices can display clear color images. In moonlit conditions, Tube NV excels at capturing clear target details. Leverage the power of a 1980×1080 sensor with 4μm pixels for exceptional low-light sensitivity. Paired with a vibrant 1440×1080 OLED display, experience unparalleled precision and clarity in night shooting. Elevate your shooting experience with this unbeatable technology combination.
1:1 Lossless Image Transmission
The TD70L V2 uses direct full-field screen capture for transmitting without any resolution missing, providing lossless images to achieve the clearest vision.
70mm Focal Length
A longer focal length of lens could provide a better hunting experience for distant targets with an improvement in magnification.
Three Image modes
There are three image modes inside of the TD70L V2. Day mode, Moon mode and Star mode. Under the Day mode there is an extraordinary display of true colors to the authentic scene in visible sight. Under the Moon and Star Mode TD70L not only seeks to offer users ultimate nighttime visibility but also offer a clear imaging display in the view range of observation without any delay. The specially designed Star mode still creates a clear night vision range even in ultra-low-light conditions or a moonless night.
Unveiling Day and Night’s Secrets
During daylight hours, from dawn to dusk, when it’s challenging for the human eye to discern target details, TUBE NV enhances your target recognition capabilities.
Recoil Activated Video
The Tube NV offers an impressive array of features, including the Recoil Activated Video (RAV) function and the Mic function. Never miss a captivating moment again with RAV, as it automatically records the moments before and after your shot. Plus, with the Mic function, you can capture not only the visuals but also the accompanying audio, enhancing the overall experience. Experience the power of complete sensory immersion with the Tube NV.
Classic Aesthetics
The Tube NV not only boasts a timeless and classical-style design that perfectly complements 30 mm standard mount rings, but it also allows for easy switching between traditional white light scopes and the Tube NV without the need for changing mount fixtures. This combination caters to the discerning needs of professional hunters who hold tradition in high regard, while also appreciating the convenience of modern technology. Experience the perfect fusion of aesthetics, functionality, and user-friendly design with the Tube NV.
Compatible with Standard 30-mm Scope Rings
The newly designed TD70L can be installed on standard 30mm scope rings. Therefore the scope can be easily mounted on a rifle’s Picatinny rail system with simple operation, stability and reliability. It is a classic yet also a practical in design.
IP67 Protection Rate
The TD70L features an IP67 level of protection, which means it is fully waterproof and dustproof. The riflescopes are able to operate in high humidity, heavy rain, or precipitation of any intensity. They are also proofed to cope with 1m-deep submersion.
Picture-in-Picture Mode (PIP)
The Picture-in-Picture function in the TD70L improves aiming accuracy by providing a 2x-magnified image of the reticle area at the top of the display. It helps users to zoom in on a target while maintaining visibility of the entire field of view for increased situational awareness.
Explore our other InfiRay thermal and night vision optics here.
InfiRay TD70L V2 Specifications
| Model | TD70LV2 | |
| Detector Specifications | Sensor Resolution, pixels | 1920 × 1080 |
| Pixel Size, μm | 4 | |
| Frame Rate, Hz | 50/25/Auto | |
| Optical Specifications | Objective Lens, mm | 70mmF1.8 |
| Field of View, º | 4.7×3.5 | |
| Linear Field of View(H×V),m@100m | 8.2×6.2 | |
| Optical Magnification, × | 5.5~22.0 | |
| Digital Zoom, × | 1 ~ 4 | |
| Eye Relief, mm | 45 | |
| Diopter Adjustment, D | -4 ~ +4 | |
| Detection Range, m | 300 | |
| Display Specifications | Type | OLED |
| Resolution, pixels | 1440×1080 | |
| Battery Power Supply | Battery Type | Built-in 6600mAh Battery Pack |
| Max. Operating Time(t=22ºC)*, h | 9 | |
| External Power Supply | 5V (Type C) | |
| Physical Specifications | Wi-Fi / APP | Support (InfiRay outdoor) |
| Photo / Video Recorder | Support | |
| Memory Capacity, GB | 32 | |
| IP Rating | IP67 | |
| Operating Temperature,°C | -20 ~ +50 | |
| Weight(Without the 18500 Battery), g | 945 | |
| Dimension, mm | 383 × 86 × 75 | |
| Body Material | Aluminum | |
| Connections and Compatibilities | Max. Recoil Power on Rifled Weapon (Eo), Joules | 6000 |
| Aim Point, MOA/CLICK | 0.2 (5.6mm@100m) | |
| Mount | Standard 30mmrings | |
| Function | IR Illuminator**, nm | 850 / 940 (Optional) |
| IR Power, w | 3 | |
| Mount | 30mm Rings | |
| Functions | Laser Rangefinder | Support (Optional) |
