Excellent NV Capability
Combination of 50mm/F1.2 large and quality objective lens with 1440×1080 resolution CMOS HD sensor with ultra-low light performance and high definition display, powerful IR Illuminator, integrated highly effective algorithm, etc. make the InfiRay TD50L the perfect digital night vision riflescope with excellent nighttime sensitivity and night vision capabilities for users, even on moonless nights.
Three Image modes
There are three image modes inside of the TD50L-Day mode, Moon mode and Star mode. Under the Day mode there is an extraordinary display of true colors to the authentic scene in visible sight. Under the Moon and Star Mode TD50L not only seek to offer users ultimate nighttime visibility but also offer a clear imaging display in the view range of observation without any delay. The specially designed Star mode still creates a clear night vision range even in ultra-low-light conditions or a moonless night.
600 m Nighttime Viewing Range
The InfiRay TD50L is a perfect tool for detecting targets such as a wild boar or deer at distances ranging up to 600 meters in nighttime as a result of the combination of the best nighttime sensitivity in its class, HD resolution display.
4x-16x Smooth Continuous Zoom
The base magnification of TD50L increases by four times – from 4x to 16x. Compared with normal integrally multiple zoom-in, TD50L allows users to zoom continuously and gradually from 4x to 16x where is a customized field of view and smooth zoom of screen display can be enjoyed. A flexible zoom-in and out function can be handled in your hands.
Dual Power Supply System
TD50L digital NV riflescopes are powered with two kinds of rechargeable batteries: built-in 6600mAh battery and the other replaceable 18500 battery located in the battery compartment which supports a over 13H battery life. When discharge of the battery in the battery compartment, the riflescope switches automatically to the built-in battery. The replaceable 18500 battery can be removed and replaced in seconds without intermediate shutdown happens on the riflescope.
Compatible with Standard 30-mm Scope Rings
The newly designed standard 30mm-diameter tubular appearance allows the TD50L to be installed on standard 30mm scope rings and easily mounted on a rifle’s Picatinny rail system with simple operation, stability and reliability. It is a classic also practical construction design.
IP67 Protection Rate
The TD50L features an IP67 level of protection, which means it is fully waterproof and dustproof. The riflescopes are able to operate in high humidity, heavy rain or precipitation of any intensity and survive a long time and the 1m-deep submersion.
Picture-in-Picture Mode (PIP)
The Picture-in-Picture function in the TD50L improves aiming accuracy by providing a 2x-magnified image of the reticle area at the top of the display. It helps users to zoom in on a target while maintaining visibility of the entire field of view for increased situational awareness.
New Freeze Zeroing Function
A new Freeze function is inside the TD50L. The biggest advantage brought by this special function is the flexibility on moving your guns when zeroing and without any influences on the zeroing data that is kept inside of storage.
Integrated Wi-Fi and InfiRay APP Support
The built-in Wi-Fi module of TD50L allows users to connect NV riflescopes with devices using the InfiRay Outdoor APP. This connection will open up a range of options for users such as photo and video storage, etc. as well as other features options under development.
Useful Reticles Design
TD50L digital night vision riflescope has 6 optional basic reticles to fit users’ different preferences, when users zoom in or out the screen display by rotating the knob, the reticle scales up or down proportionally to the riflescope’s magnification changes and remain constant on dimension and details part, allow users to adjust for various shooting distance needs.
Resolution: 1440×1080 pixels
Frame Rate: 50Hz
Objective Lens: 50mm (F1.0)
Field of View: 6.6×4.9°
Smooth zoom: Support
Eye Relief: 70mm
Diopter Adjustment: -4~+4D
Resolution: 1280×960 pixels
Video record resolution: 1440×1080pixels
Capture resolution: 1440×1080pixels
Detection range: 600m
Battery: Built-in 6600mAh and a replaceable 1500mAh
Max. Operating Time (at temp.=22 °C): >16h
External power supply: 5V (Type C USB)
Diameter of the riflescope body to assemble the mounting rings: 30mm
Max. Recoil Power on Rifled Weapon: 1000g/s2
Degree of protection: IP67
Amount of built-in memory: 16GB
Weight (without replaceable battery): <1000g
Smart range finder: Support
Electronic compass: Support
Motion sensor: Support
IR illuminator: Not included
Max Power of IR illuminator: 2.2W
