The NocPix ACE S60R is an infrared scope for outdoor hunting. Designed based on infrared thermal imaging principles, it requires no external light sources during the day and at night, in all hard weather conditions (such as rain, snow, fog, and haze). It can be used without being affected by strong light and to observe even targets behind obstacles (such as branches, grass, and shrubs). ACE series has a variety of battery-powered solutions with long operating hours, and can be widely used for hunting, observation and positioning in low visibility conditions.
Introducing the ACE series, the flagship thermal riflescope designed for all hunting environments. It features a self-developed high-resolution thermal sensor, integrated LRF, and advanced Reality+ and Vision+ systems. Deliver unparalleled image quality and superior performance.
Superior Sensor Ensures Excellence
Equipped with a Gen-2 HD thermal sensor offering a resolution of up to 1280×1024 and a frame rate of up to 60Hz, the ACE provides stable performance with an NETD≤15mK. This enables it to detect even the slightest temperature variations, delivering exceptionally detailed and smooth thermal imagery, even when tracking fast-moving prey.
Enhanced Clarity with Larger Lens
The S60R features a 60mm lens. The larger objective lens allows 20% more light to reach the sensor. Coupled with high-transmittance lens elements, it generates brighter and clearer images.
Long-Distance Detection at Ease
The ACE series boasts an impressive detection range of up to 3100 meters. This capability allows clear identification of distant targets, providing a significant advantage for long-range hunting.
Reality+ Imaging Enhancement
Our proprietary Reality+ image processing algorithm effectively eliminates environmental temperature noise, enhancing contrast and detail clarity.
Agile and Precise Built-in LRF
The ACE is equipped with an integrated LRF, offering laser range-finding up to 1200 meters with true optical axis alignment, ensuring precise distance measurements while maintaining a sleek and elegant design.
New Vision+ System with Ocular Zoom
The new Vision+ system features a 1.03-inch, round, 2560×2560 AMOLED screen and industry-leading ocular zoom for direct optical magnification. Unlike traditional e-zoom, it prevents blurring and distortion in close-up views. Enjoy high-resolution images and a broader field of view for an immersive and comfortable observation experience.
Eliminate Battery Capacity Concerns
The ACE employs a dual-battery system with a 4000mAh built-in battery and an additional replaceable 18650 battery. This setup meets the demands of prolonged outdoor hunting sessions.
Designed for Hunting and Shooting
The ACE includes essential features for hunting scenarios such as ballistic calculations, auto screen shutdown, recoil-activated video recording, and a shutterless design, making perfect hunting achievable.
Outdoor-Friendly Design
The ACE incorporates thoughtful features such as a focus adjuster, charging cover, and a Gallery feature for direct video playback, significantly enhancing user convenience.
Rigorous Testing & High-durability
Crafted from high-strength aluminum alloy, the ACE undergoes rigorous impact resistance testing, ensuring exceptional robustness and durability for years to come.
Package Contents
- ACE Series Thermal Imaging Scope
- Heated target for zeroing
- Lens cloth
- 2 x 18650 battery
- Type-C cable
- Quick start guide
- Battery charger
- Portable bag
NocPix ACE S60R Thermal Rifle Scope Specifications
| Model | NPRIF-ACE- S60R |
| Magnification | 2~24 |
| Objective Lens | 60mm ƒ1.0 |
| Battery | Built-in battery/4000mAh + Replaceable 18650 battery |
| Weight | 45.86oz/ 1300g |
| NETD, mk | ≤ 15 |
| Type | Vox |
| Resolution | 1280 x 1024 |
| Pixel Size | 12MP |
| Frame Rate | 50fps |
| Field of View | 14.7 x 11.7 |
| Field of View (Liner) | 25.6 x 20.5 |
| Dimensions | 15.35 x 3.54 x 2.8″ /390 x 90 x 71mm |
| Thermal Sensor | 1280 x 1024 12μ |
| Detection Range | 3100m |
| Eye Relief | 50 |
| Exit Pupil Diameter | 8 |
| Dipoter | -5 ~ +5 |
| Display Type | AMOLED |
| Display Resolution | 2560 x 2560 |
| Max Operating Time | 7hrs |
| External Power Supply | 5V (Type C) |
| WiFi | YES |
| Mic | YES |
| Memory Card Capacity | 64GB |
| IP Rating | IP67 |
| Max Recoil Power | 6000 |
| Max Operating Temperature | -20 ~ +50 °C |
| Compatible Mount | 30mm |
| Range Finding Distance | 1200 |
| Laser | Class 1 |
| Ballistic Calculation | YES |
| Photo Video Recorder | YES |
| Recoil Activated Video | YES |
